Protective Coating
4 Products
MC PC20E - 5.00 l
Regular price:
From
€298.00
1MPC20E5000
Bottle size:
5.00 l
MC PC20E
Protective Coating
General Information
Products of the MC PC series are transparent, protective coatings for the semiconductor industry.
They are based on a high quality Novolak resin and the solvents Ethyllactate and Butylacetate. The recipe is similar to the ingredients of a common positive photoresist, but without the photoactive compound (PAC). They can be used for many applications where photolithographic patterning is not required.
Product Properties
With MC PC20E, a film thickness of approximately 2 µm can be achieved by spincoating at 4000 rpm. However, the optimum values e.g. spin profile, coating method and remover depend on the individual equipment and need to be adjusted on each individual demand.
Fields of Application
Protective Coating for mechanical protection
Grinding and dicing processes
Other mechanical treatments
Protective Coating for etching and plating processes
The MC PC Series Resists are resistant to most (acidic) etchants and plating solutions
It can be used in dry etching processes as well
Removers
The PC series is compatible with a broad range of strippers for positive resists, solvents and bases. Suitable options include AZ 100 Remover, Technistrip P1316 or AZ Remover 920, as well as Solvents or bases like DMSO or Acetone, respectively.
Thinning/ Edge Bead Removal
For thinning, we recommend MC BuEL Solvent.
Further Information
MSDS:
Safety Data Sheet MC PC20E Protective Coating english
Safety Data Sheet MC PC20E Protective Coating german
TDS:
Technical Data Sheet MC PC series english
Application Notes:
Further Information about Photoresist Processing
MC PC20EC - 5.00 l
Regular price:
From
€298.00
1MCPC20EC5000
Bottle size:
5.00 l
MC PC20EC
Protective Coating
General Information
Products of the MC PC series are transparent, protective coatings for the semiconductor industry.
They are based on a high quality Novolak resin and the solvents Ethyllactate and Butylacetate. The recipe is similar to the ingredients of a common positive photoresist, but without the photoactive compound (PAC). They can be used for many applications where photolithographic patterning is not required.
Product Properties
With MC PC20EC, a film thickness of approximately 2 µm can be achieved by spincoating at 4000 rpm. However, the optimum values e.g. spin profile, coating method and remover depend on the individual equipment and need to be adjusted on each individual demand.
MC PC20EC is the blue-green coloured variation for easy visual inspection after coating.
Fields of Application
Protective Coating for mechanical protection
Grinding and dicing processes
Other mechanical treatments
Protective Coating for etching and plating processes
The MC PC Series Resists are resistant to most (acidic) etchants and plating solutions
It can be used in dry etching processes as well
Removers
The PC series is compatible with a broad range of strippers for positive resists, solvents and bases. Suitable options include AZ 100 Remover, Technistrip P1316 or AZ Remover 920, as well as Solvents or bases like DMSO or Acetone, respectively.
Thinning/ Edge Bead Removal
For thinning, we recommend MC BuEL Solvent.
Further Information
MSDS:
Safety Data Sheet MC PC20EC Protective Coating english
Safety Data Sheet MC PC20EC Protective Coating german
TDS:
Technical Data Sheet MC PC series english
Application Notes:
Further Information about Photoresist Processing
MC PC62E - 5.00 l
Regular price:
From
€308.00
1MPC62E5000
Bottle size:
5.00 l
MC PC62E
Protective Coating
General Information
Products of the MC PC series are transparent, protective coatings for the semiconductor industry.
They are based on a high quality Novolak resin and the solvents Ethyllactate and Butylacetate. The recipe is similar to the ingredients of a common positive photoresist, but without the photoactive compound (PAC). They can be used for many applications where photolithographic patterning is not required.
Product Properties
With MC PC62E, a film thickness of approximately 6.2 µm can be achieved by spincoating at 4000 rpm. However, the optimum values e.g. spin profile, coating method and remover depend on the individual equipment and need to be adjusted on each individual demand.
Fields of Application
Protective Coating for mechanical protection
Grinding and dicing processes
Other mechanical treatments
Protective Coating for etching and plating processes
The MC PC Series Resists are resistant to most (acidic) etchants and plating solutions
It can be used in dry etching processes as well
Removers
The PC series is compatible with a broad range of strippers for positive resists, solvents and bases. Suitable options include AZ 100 Remover, Technistrip P1316 or AZ Remover 920, as well as Solvents or bases like DMSO or Acetone, respectively.
Thinning/ Edge Bead Removal
For thinning, we recommend MC BuEL Solvent.
Further Information
MSDS:
Safety Data Sheet MC PC62E Protective Coating english
Safety Data Sheet MC PC62E Protective Coating german
TDS:
Technical Data Sheet MC PC series english
Application Notes:
Further Information about Photoresist Processing
MC PC62EC - 5.00 l
Regular price:
From
€308.00
1MCPC62EC5000
Bottle size:
5.00 l
MC PC62EC
Protective Coating
General Information
Products of the MC PC series are transparent, protective coatings for the semiconductor industry.
They are based on a high quality Novolak resin and the solvents Ethyllactate and Butylacetate. The recipe is similar to the ingredients of a common positive photoresist, but without the photoactive compound (PAC). They can be used for many applications where photolithographic patterning is not required.
Product Properties
With MC PC62EC , a film thickness of approximately 6.2 µm can be achieved by spincoating at 4000 rpm. However, the optimum values e.g. spin profile, coating method and remover depend on the individual equipment and need to be adjusted on each individual demand.
MC PC62EC is the blue-green coloured variation for easy visual inspection after coating.
Fields of Application
Protective Coating for mechanical protection
Grinding and dicing processes
Other mechanical treatments
Protective Coating for etching and plating processes
The MC PC Series Resists are resistant to most (acidic) etchants and plating solutions
It can be used in dry etching processes as well
Removers
The PC series is compatible with a broad range of strippers for positive resists, solvents and bases. Suitable options include AZ 100 Remover, Technistrip P1316 or AZ Remover 920, as well as Solvents or bases like DMSO or Acetone, respectively.
Thinning/ Edge Bead Removal
For thinning, we recommend MC BuEL Solvent.
Further Information
MSDS:
Safety Data Sheet MC PC62EC Protective Coating english
Safety Data Sheet MC PC62EC Protective Coating german
TDS:
Technical Data Sheet MC PC series english
Application Notes:
Further Information about Photoresist Processing
