Fused silica JGS1 wafer 1 inch 1000 um DSP
Ab
4,40 €*
WUS11000500X0000SNN1
Fused silica JGS1 wafer 1 inch, thickness = 1000 ± 50 µm, 2-side polished, TTV < 10 µm, no Flat
Fused silica JGS1 wafer 2 inch 500 um DSP
Ab
10,00 €*
WUS20500250X0000SNN2
Fused silica JGS1 wafer 2 inch, thickness = 500 ± 25 µm, 2-side polished, TTV < 10 µm, 1 SEMI Flat, !! Units of 10 wafers per cassette
Fused silica JGS1 wafer 2 inch 500 um DSP
Ab
9,00 €*
WUS20500250XXXXXSNN1
Fused silica JGS1 wafer 2 inch, thickness = 500 ± 25 µm, 2-side polished, TTV < 10 µm, 1 SEMI Flat
Fused silica JGS1 wafer 4 inch 1000 um DSP
Ab
37,00 €*
WUS41000250X0000SNN1
Fused silica JGS1 wafer 4 inch +/- 0.3 mm, thickness = 1000 ± 25 µm, 2-side polished, TTV < 10 µm, primary flat 32.50mm, Bow/Warp < 40 µm, S/D 40/20
Fused silica JGS1 wafer 6 inch 1000 um DSP
Ab
58,00 €*
WUS61000250X0000SNN2
Fused silica JGS1 wafer 6 inch, thickness = 1000 ± 25 µm, 2-side polished, 1 flat
Fused silica JGS1 wafer 8 inch 700 um DSP
Ab
90,00 €*
WUS80700250X0000SNN2
Fused silica JGS1 wafer 8 inch, thickness = 700 ± 25 µm, 2-side polished, 1 SEMI Notch
Fused silica JGS2 wafer 1 inch 500 um DSP
Ab
4,20 €*
WUS10500250X0000XNN1
Fused silica JGS2 wafer 1 inch, thickness = 500 ± 25 µm, 2-side polished, TTV < 10 µm, no Flat
Fused silica JGS2 wafer 1 inch 500 um DSP
Ab
6,90 €*
WUS10500250X0000SNN1
Fused silica JGS2 wafer 1 inch (!! 25.0 +/- 0.3 mm !!), thickness = 500 ± 25 µm, 2-side polished, 1 Flat
Fused silica JGS2 wafer 10 x 10 mm 170 um DSP
Ab
1,50 €*
W9US0100100170NNNNX1
Fused silica JGS2 wafer piece (10 x 10 mm), thickness = 170 ± 20 µm, 2-side polished, optical grade, units of 40 pieces
Fused silica JGS2 wafer 10 x 10 mm 500 um DSP
Ab
2,20 €*
W9US0100100500NNNNX1
Fused silica JGS2 wafer piece (10 x 10 mm), thickness = 500 ± 25 µm, 2-side polished, optical grade (40 Wafer/Box)
Fused silica JGS2 wafer 10 x 20 mm 500 um DSP
Ab
2,60 €*
W9US0100200500NNNNX1
Fused silica JGS2 wafer piece (10 x 20 mm), thickness = 500 ± 25 µm, 2-side polished, units of 40 pieces
Fused silica JGS2 wafer 100 x 100 mm 200 um DSP
Ab
23,00 €*
W9US1001000200NNNNX2
Fused silica JGS2 wafer piece (100 x 100 mm), thickness = 200 ± 10 µm, , 2-side polished, TTV < 10 µm, Bow < 40 µm, Warp < 40 µm, S/D 40/20, packed in units of 10 wafers
Fused silica JGS2 wafer 15 x 11,5 mm 1000 um DSP
Ab
5,60 €*
W9US0150111000NNNNX1
Fused silica JGS2 wafer piece (15 x 11,5 mm), +0.0/-0.5 mm, thickness = 1000 ± 25 µm, 2-side polished, units of 20 pieces
Fused silica JGS2 wafer 2 inch 1000 um DSP
Ab
6,80 €*
WUS21000250X0000XNN1
Fused silica JGS2 wafer 2 inch, thickness = 1000 ± 25 µm, 2-side polished, TTV < 10 µm, no flat
Fused silica JGS2 wafer 2 inch 200 um DSP
Ab
12,00 €*
WUA20200250X0000SNN1
Fused silica JGS2 wafer 2 inch, thickness = 200 ± 25 µm, 2-side polished, No Flat
Fused silica JGS2 wafer 2 inch 3600 um DSP
Ab
15,00 €*
WUS23600500X0000XNN1
Fused silica JGS2 wafer 2 inch, thickness = 3600 ± 50 µm, 2-side polished, no flat, film packing, units of 5 wafers per bag
Fused silica JGS2 wafer 2 inch 380 um DSP
Ab
7,50 €*
WUS20380250X0000XNN1
Fused silica JGS2 wafer 2 inch, thickness = 380 ± 25 µm, 2-side polished, TTV < 10 µm
Fused silica JGS2 wafer 2 inch 500 um DSP
Ab
7,00 €*
WUS20500250X0000SNN1
Fused silica JGS2 wafer 2 inch, thickness = 500 ± 25 µm, 2-side polished, TTV < 10 µm, 1 flat
Fused silica JGS2 wafer 2 inch 500 um DSP
Ab
6,00 €*
WUS20500250X0000XNN1
Fused silica JGS2 wafer 2 inch, thickness = 500 ± 25 µm, 2-side polished, no flat
Fused silica JGS2 wafer 20 x 20 mm 700 um DSP
Ab
2,90 €*
W9US0200200700NNNNX1
Fused silica JGS2 wafer piece (20 x 20 mm), thickness = 700 ± 25 µm, 2-side polished, units of 30 pieces
Fused Silica JGS2 Wafer 25 x 25 mm 700 um DSP
Ab
2,20 €*
W9UA0250250700NNNNX1
Fused silica JGS2 wafer piece (25 x 25 mm), thickness = 700 ± 25 µm, 2-side polished
sales units of 50 items *
Fused silica JGS2 wafer 3 inch 1000 um DSP
Ab
14,00 €*
WUS31000250X0000SNN1
Fused silica JGS2 wafer 3 inch, thickness = 1000 ± 25 µm, 2-side polished, TTV < 10 µm, roughness 1 nm, 1 SEMI Flat
Fused silica JGS2 wafer 3 inch 320 um DSP
Ab
9,00 €*
WUA30320100X0000SNN1
Fused silica JGS2 wafer 3 inch, thickness = 320 ± 10 µm, 2-side polished, TTV < 10 µm
Fused silica JGS2 wafer 3 inch 380 um DSP
Ab
10,00 €*
WUA30380200X0000SNN1
Fused silica JGS2 wafer 3 inch, thickness = 380 ± 20 µm, 2-side polished, TTV < 10 µm
