n-Butylacetat - 5.00 l - VLSI
TECHNIC France
Butyl Acetate is used in the fields of semiconductor processing and microelectronics.
The prices are visible after registration.
Send us an inquiry if you have any questions about articles, purchase quantities, delivery times or sample requests!
Product number:
TNBAV1050
Manufacturer:
TECHNIC France
Description
Product information "n-Butylacetat - 5.00 l - VLSI"
Butyl Acetate
C6H12O2
General Information
Butyl Acetate is a solvent with a boiling point of 127°C. The vapour pressure at room temperature is 10.7 hPa. Butyl Acetate has the chemical formula C6H12O2. It can be easily solved in nonpolar (organic) solvents, but fairly bad in water (4.3 g per Litre).
Product Properties
- Density: 0.88 g/cm3
- Melting point: -77°C
- Boiling point: 127°C
- Flash point: 27°C
- Vapour pressure @ 20°C: 10.7 hPa
Further Information
MSDS:
Safety Data Sheet Butyl Acetate (VLSI) english
Sicherheitsdatenblatt Butyl Acetate (VLSI) german
Specs:
Specs Butyl Acetate (VLSI)
Application Notes:
Solvents: Theory and Application english
Lösemittel: Theorie und Anwendung german
