FZ-Wafer (Float-Zone)
FZ-Si wafer 2 inch 1500 um (100) DSP B-doped
WFA21500250B3618SNN1
Prime FZ-Si wafer 2 inch, thickness = 1500 ± 25 µm, (100), 2-side polished, p-type (Boron), TTV < 10 µm, 2 Flats, 3000 - 100000 Ohm cm
Lagerbestand:
123
Ab
28,00 €*
FZ-Si wafer 2 inch 1600 um (100) SSP B-doped
WFD21600250B3638SNN1
Prime FZ-Si wafer 2 inch, thickness = 1600 ± 25 µm, (100), 1-side polished, p-type (Boron) TTV < 10 µm, > 3000 ohm cm, 2 SEMI Flats, bow/warp < 40 µm
Lagerbestand:
18
Ab
19,00 €*
FZ-Si wafer 2 inch 1600 um (100) SSP P-doped
WFD21600250P3638SNN1
Prime FZ-Si wafer 2 inch, thickness = 1600 ± 25 µm, (100), 1-side polished, n-type (Phosphor TTV < 10 µm, > 3000 ohm cm, 2 SEMI Flats, bow/warp < 40 µm
Lagerbestand:
27
Ab
19,00 €*
FZ-Si wafer 2 inch 280 um (100) DSP
WFA20280100X1718XNN1
Prime FZ-Si wafer 2 inch, thickness = 280 ± 10 µm, (100), 2-side polished, TTV < 10 µm, 10000 - 100000 Ohm cm
Lagerbestand:
65
Ab
15,00 €*
FZ-Si wafer 2 inch 280 um (100) SSP
WFD20280250X1719XNN1
Prime FZ-Si wafer 2 inch, thickness = 280 ± 25 µm, (100), 1-side polished, TTV < 10 µm, 10000 - 1000000 Ohm cm, no Flat, units of 25 wafers
Lagerbestand:
75
Ab
12,80 €*
FZ-Si wafer 2 inch 300 um (100) SSP
WFD20300105X5619SNN2
Prime FZ-Si wafer 2 inch, thickness = 300 ± 10 µm, (100), 1-side polished, TTV < 5 µm, 5000 - 1000000 Ohm cm, Flats: 2
Lagerbestand:
137
Ab
12,50 €*
FZ-Si wafer 2 inch 415 um (111) SSP
WFF20415150X1718XNN1
Prime FZ-Si wafer 2 inch, thickness = 415 ± 15 µm, (111), 1-side polished, TTV < 10 µm, 10000 - 100000 Ohm cm, undoped/intrinsic
Lagerbestand:
62
Ab
14,00 €*
FZ-Si wafer 2 inch 500 um (100) DSP B-doped
WFA20500150B1618SNN1
Prime FZ-Si wafer 2 inch, thickness = 500 ± 15 µm, (100), 2-side polished, p-type (Boron), TTV < 10 µm, 1000 - 100000 Ohm cm
Lagerbestand:
115
Ab
12,50 €*
FZ-Si wafer 2 inch 500 um (100) DSP P-doped
WFA20500150P1618SNN1
Prime FZ-Si wafer 2 inch, thickness = 500 ± 15 µm, (100), 2-side polished, n-type (Phosphor), TTV < 10 µm, 1000 - 100000 Ohm cm
Lagerbestand:
114
Ab
12,50 €*
FZ-Si wafer 3 inch 320 um (100) DSP
WFA30320100X1718SNN1
Prime FZ-Si wafer 3 inch, thickness = 320 ± 10 µm, (100), 2-side polished, TTV < 10 µm, undoped, 10000 - 100000 Ohm cm
Lagerbestand:
164
Ab
36,00 €*
FZ-Si wafer 3 inch 380 um (100) SSP
WFD30380105X1719SNN2
Prime FZ-Si wafer 3 inch, thickness = 380 ± 10 µm, (100), 1-side polished, TTV < 5 µm, 10000 - 1000000 Ohm cm, Flats: 2, [InvP]
Lagerbestand:
225
Ab
29,00 €*
FZ-Si wafer 4 inch 200 um (100) DSP
WFA40200105X1719XNN1
Prime FZ-Si wafer 4 inch, thickness = 200 ± 10 µm, (100), 2-side polished, TTV < 5 µm, 10000 - 1000000 Ohm cm
Lagerbestand:
368
Ab
43,00 €*
FZ-Si wafer 4 inch 280 um (100) DSP B-doped
WFA40280100B2686SNN1
Prime FZ-Si wafer 4 inch, thickness = 280 ± 10 µm, (100), 2-side polished, p-type (Boron) TTV < 10 µm, 2000 - 8000 Ohm cm, 1 SEMI flat
Lagerbestand:
234
Ab
41,00 €*
FZ-Si wafer 4 inch 290 um (100) DSP B-doped
WFA40290100B2686SNN1
Prime FZ-Si wafer 4 inch, thickness = 290 ± 10 µm, (100), 2-side polished, p-type (Boron) TTV < 10 µm, 2000 - 8000 Ohm cm, 2 flats
Lagerbestand:
2
Ab
41,00 €*
FZ-Si wafer 4 inch 300 um (111) DSP
WFC40300250X1718SNN1
Prime FZ-Si wafer 4 inch, thickness = 300 ± 25 µm, (111) +/- 0.5°, 2-side polished, TTV < 10 µm, 10000 - 100000 Ohm cm (intrinsic), Bow/Warp < 30 µm
Lagerbestand:
23
Ab
42,00 €*
FZ-Si wafer 4 inch 300 um (111) SSP
WFF40300155X1719SNN1
Prime FZ-Si wafer 4 inch, thickness = 300 ± 15 µm, (111), 1-side polished, TTV < 5 µm, 10000 - 1000000 Ohm cm, Flats: 2
Lagerbestand:
171
Ab
42,50 €*
FZ-Si wafer 4 inch 400 um (100) DSP P-doped
WFA40400105P3619SNN1
Prime FZ-Si wafer 4 inch, thickness = 400 ± 10 µm, (100), 2-side polished, n-type (Phosphor) TTV < 5 µm, 3000 - 1000000 Ohm cm, Flats: 2
Lagerbestand:
381
Ab
33,00 €*
FZ-Si wafer 4 inch 500 um (100) DSP B-doped
WFA40500150B3618SNN1
Prime FZ-Si wafer 4 inch, thickness = 500 ± 15 µm, (100), 2-side polished, p-type (Boron) TTV < 10 µm, 3000 - 100000 Ohm cm
Lagerbestand:
55
Ab
41,20 €*
FZ-Si wafer 4 inch 525 um (100) DSP
WFA40525105X1718XNN1
Prime FZ-Si wafer 4 inch, thickness = 525 ± 10 µm, (100), 2-side polished, TTV < 5 µm, undoped/intrinsic, 10000 - 100000 Ohm cm, 1 SEMI Flat
Lagerbestand:
178
Ab
40,00 €*
FZ-Si wafer 4 inch 525 um (111) DSP P-doped
WFC40525155P2619SNN1
Prime FZ-Si wafer 4 inch, thickness = 525 ± 15 µm, (111), 2-side polished, n-type (Phosphor) TTV < 5 µm, 2000 - 1000000 Ohm cm, Flats: 2, [InvP]
Lagerbestand:
45
Ab
37,50 €*
FZ-Si wafer 6 inch 300 um (100) DSP
WFA60300100X1718SNN1
Prime FZ-Si wafer 6 inch, thickness = 300 ± 10 µm, (100), 2-side polished, 10000 - 100000 Ohm cm, 1 SEMI Flat, Laser-marking on rear side “BacksideXXX”, xx = 001 – 999
Lagerbestand:
123
Ab
78,00 €*
FZ-Si wafer 6 inch 380 um (100) DSP
WFA60380100X1718SNN1
Prime FZ-Si wafer 6 inch, thickness = 380 ± 10 µm, (100), 2-side polished, TTV < 10 µm, 10000 - 100000 Ohm cm
Lagerbestand:
112
Ab
95,00 €*
